48v lead acid battery charger 240w 58.4v 5 amp lithium lifep04 battery charger
48v lead acid battery charger 240w 58.4v 5 amp lithium lifep04 battery charger
Couldn't load pickup availability
I. SPECIFICATION
| Brand |
IDEALPLUSING/OEM |
||
| Series No |
240W Series |
||
| Model No |
IPS-BC48-5 |
||
| Input Voltage |
200~240VAC, 50HZ/60HZ |
||
| Nominal Voltage |
48VDC |
||
| Charging Current |
5A |
||
| Housing |
Aluminum Alloy |
||
| Net /Gross Weight |
1KG/1.3KG |
||
| Product dimension |
L135*W90*H50(MM) |
||
| Package dimension |
L165*W120*H80MM) |
||
| CV-Lead acid-14.7V |
58.8V(4S) |
||
| CV-LiFePO4-3.65V |
58.4V(16S) |
||
| CV-Lithium-4.2V |
54.6V(13S)/58.8V(14S) |
||
| Charging Principle |
Full automatic transition CC, CV, and Float/Cut-off |
||
| Charging Time |
The cut-off point for Li battery is 5% of CC and it can be set between 3-10%. |
||
| Transition for Lead acid charger is 20% of CC. |
|||
| High-Efficiency |
≥90% |
||
| MTBF |
≥50000h |
||
| Operating Temperature |
-20℃~50℃ |
||
| Store Temperature |
(-40~80)℃ |
||
| Related humility |
90%(40±2℃) |
||
| Protection Function |
Overvoltage |
Over Temperature |
Over Current |
| Short circuit |
/ |
||
| Indicators |
Red means power on / charging, and Green means fully charged |
||
| AC Plug |
Accept any plug base on your request |
||
II. INTRODUCTION
Most of the traditional chargers and simple chargers are made up of industrial frequency transformers and rectifier circuits (silicon-controlled rectifiers (SCR)). Even use the silicon-controlled rectifier to adjust the AC mains supply to charge the battery. Though this circuit is simple, it has disadvantages:
| 1 |
Big volume and high weight, not convenient for transportation and use |
| 2 |
Lacking protection function, bad reliability |
| 3 |
Must manually adjust the charge current, difficult to fully charge and avoid overcharging the battery. |
| 4 |
Silicon-controlled rectifier adjusts the AC mains supply to charge the battery directly. Then there is no isolation with AC mains supply which is dangerous to get an electric shock. And it will damage the AC mains supply waveform. |
III. ADVANTAGE
| 1 |
Short-circuit protection: output current will cut off automatically when short-circuit. |
| 2 |
Overload protection: Output Current Will Be Limited Automatically When Overload. |
| 3 |
Reverse polarity protection: it will shut down until the fuse or the fault is removed. |
| 4 |
2-stage charging mode: CC(Constant Current), CV(Constant Voltage) |
| 5 |
Long lifetime: In the MTBF test, it makes more than 30,000 POH (power on hours), which means about 10 years if it works 8 hours every day. |
| 6 |
LED Meter available: Show Charging Voltage and Charging Current. |
| 7 |
All kinds of products have passed the CE certification and ROHS. |
| 8 |
Efficiency: 90%( full capacity). |
